A 3D printed forming tool used to create a V-fold in sheet metal made with FDM PC (polycarbonate) material.

PC (Polycarbonate) FDM Filament

FDM Thermoplastic
PC FDM Filament With High Impact Strength

Polycarbonate FDM filament is a strong, dimensionally stable, heat-resistant thermoplastic notable for its high impact strength. These characteristics mean the parts you print retain their shape and dimensional accuracy. In addition, polycarbonate’s high impact strength provides toughness, making it a suitable material for high-durability applications that include functional prototyping, manufacturing tooling, and low-volume end-use parts.

Compared to other unfilled FDM engineering plastics, PC offers one of the most durable materials relative to strength and toughness. FDM PC also offers high compression strength for this class of materials and can be used for metal-forming dies for production quantities in the range of 500 to 1000 units or to validate tool design before investing in final tooling.

In addition to the standard white color, black and red are available from the Stratasys Validated Material portfolio. Stratasys Validated Materials are developed by Stratasys or a third-party provider, meet Stratasys quality standards and have received basic reliability testing for use with Stratasys FDM printers.

Polycarbonate FDM filament offers a strong yet lower-cost solution compared to high-performance and filled thermoplastics for applications that require durable mechanical properties.

Typical applications

Prototyping icon

Prototyping

Concept models, early prototyping and functional prototypes.

icon Tooling

Tooling

Jigs, fixtures and manufacturing aids.

Gears icon

Production Parts

Low-volume production and highly customised parts.

Performance properties

Tensile

Tensile Yield Strength*

  • PC: 60 MPa
  • Nylon 12: 50 MPa
  • PC-ABS: 36 MPa


*XZ orientation

WARNING: This product can expose you to chemicals including ETHYLENE OXIDE, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.

Compatible printers

fortus_450mc

Fortus 450mc

Leverage the versatility of being able to print using multiple FDM materials with the Fortus 450mc printer.

Learn More
f900

F900

For big parts, large print jobs or a combination of both, rely on the F900, compatible with most Stratasys FDM thermoplastics

Learn More
F3300 3D printer

F3300

Print up to twice as fast and lower your cost per part with the F3300.

Learn More

Downloads

PC product data sheet

Download

PC safety data sheet

Continue to safety data sheet

Materials testing procedure

Download
